Double Twisted Gabion Flexible Durable Versatile Stone Retaining Wall Based Approach To Erosion Control Use Mountain

Brand Name : KN

Model Number : 2X1X1 3X1X1 4X1X1 6X2X0.3

Certification : CE ISO

Place of Origin : China

MOQ : 100pc

Price : USD 12-17

Payment Terms : L/C,T/T,Western Union,MoneyGram

Supply Ability : 1000 pc need 7 days

Delivery Time : 7-10 days

Packaging Details : pallets of Double Twisted Gabion Flexible Durable Versatile Stone Retaining Wall Based Approach To Erosion Control Use Mountain

Product Name : Double Twisted Gabion Flexible Durable Versatile Stone Retaining Wall Based Approach To Erosion Control Use Mountain

Stock : have large in stock

Tensile Strength : 350-550N/mm2

Customized : Avaliable

Wire Diameter : 2.7mm

Zinc : >275g/m²

Cage Size : 1*1*1m,2*1*1m,3*1*1m,4*1*1m

Net Wire : Popular 2.7mm

Advantages : Easy Install, Long Using Life

Twist : Double Twisting

Features : Flood bank or guiding bank

Selvage Wire : 3.4mm

Contact Now

Double Twisted Gabion Flexible Durable Versatile Stone Retaining Wall Based Approach To Erosion Control Use Mountain

Introduction

All gabions we supply have been independently tested by the British Board of Agreement (BBA). With respect to design life this therefore means

Galfan (95% Zn / 5%) supplied with a CLASS A Coat Weight– design life up to 70 years in a mild environment.

PVC coated on heavily galvanised wires – design life of up to 120 years in a mild environment.

Double Twisted Gabion Flexible Durable Versatile Stone Retaining Wall Based Approach To Erosion Control Use Mountain

Key Features

  • Features & Benefits

    High Durability – Made from galvanized or PVC-coated wire for corrosion resistance.

    Flexible Structure – Hexagonal design adapts to ground movement without losing integrity.

    Versatile Applications – Suitable for Gabions in construction, landscaping, and riverbank protection.

    Eco-Friendly – Promotes natural vegetation growth through the mesh structure.

    Customizable Sizes – Available for different Gabion basket and Gabion Box requirements.

    Aesthetic & Functional – Perfect for garden gabion decorative walls and functional erosion control.

    Double Twisted Gabion Flexible Durable Versatile Stone Retaining Wall Based Approach To Erosion Control Use Mountain

  • Mesh Sizes
    (mm)    		 Gabion basket dimensions and volumes Wire diameter
    L(M) W(M) D(M) Capacity(m³) Number of diaphragm
    60*80
    80*100
    100*120    		 4 2 0.3 2.4 3 Mesh Wire:
    2.0mm,2.2mm
    2.5mm, 2.7mm,3.05mm.
    2.0/3.0mm,2.2/3.2mm
    2.5/3.5mm,2.7/3.7mm.
    selvedge wire:
    2.5mm,2.7mm
    3.2mm,3.4mm,3.8mm
    2.5/3.5mm,2.7/3.7mm
    3.2/4.2mm,3.4/4.4mm
    lacing wire:
    2.0mm,2.2mm
    2.0/3.0mm,2.2/3.2mm
    6 2 0.3 3.6 5
    4 2 0.23 1.84 3
    6 2 0.23 2.76 5
    2 1 0.5 1 1
    3 1 0.5 1.5 2
    4 1 0.5 2 3
    2 1 1 2 1
    3 1 1 3 2
    4 1 1 4 3
    Other specifications can also be customized processing.

Application

The primary application of the Gabion Basket by Roll is slope protection in mountainous regions. It is particularly effective in preventing landslides and mudslides by:
  • Stabilizing Soil: The baskets are filled with stones or other suitable materials, creating a rigid structure that holds the soil in place and prevents it from being washed away by heavy rains.
  • Reducing Water Erosion: The porous design allows water to pass through while retaining the soil and debris, reducing the risk of erosion and mudslides.
  • Enhancing Safety: By providing a stable barrier, the Gabion Basket by Roll helps protect infrastructure, roads, and communities located near unstable slopes.
  • Double Twisted Gabion Flexible Durable Versatile Stone Retaining Wall Based Approach To Erosion Control Use Mountain

Installation

Installation of the Gabion Basket by Roll is straightforward and efficient:
  1. Site Preparation: Clear the slope of any debris and ensure the ground is level.
  2. Unrolling: Unroll the gabion baskets directly on the slope, securing them with stakes or anchors as needed.
  3. Filling: Fill the with baskets stones or other suitable materials, ensuring they are packed tightly to maximize stability.
  4. Final Securing: Secure the baskets with additional fasteners and interconnect them to form a cohesive structure.

​Double Twisted Gabion Flexible Durable Versatile Stone Retaining Wall Based Approach To Erosion Control Use Mountain

Cooperation and Services

As a professional manufacturer, we are committed to providing high-quality gabion basket solutions for global water conservancy and environmental protection projects. We maintain close cooperation with government departments in various countries and have provided reliable product support for numerous water conservancy and environmental protection projects.
Double Twisted Gabion Flexible Durable Versatile Stone Retaining Wall Based Approach To Erosion Control Use Mountain
Double Twisted Gabion Flexible Durable Versatile Stone Retaining Wall Based Approach To Erosion Control Use Mountain
